LDPE/HDPE high speed ABA film blowing machine
| Model | CX-ABA-1100 | CX-ABA-1300 | CX-ABA-1600 | CX-ABA-2000 |
| Suitable materials |
HDPE,LDPE, LLDPE,PLA+PBAT |
HDPE,LDPE ,LLDPE,PLA+PBAT | HDPE,LDPE ,LLDPE,PLA+PBAT | HDPE,LDPE ,LLDPE,PLA+PBAT |
| Film width | 500-1000mm | 600-1200mm | 1000-1500mm | 1500-2050mm |
| Film thickness | 0.02-0.20mm | 0.02-0.20mm | 0.02-0.20mm | 0.02-0.20mm |
| Output | 120kg | 150kg | 170kg | 210kg |
| LDPE | 165kg | 185kg | 225kg | |
| Extrusion unit | ||||
| Screw diameter | 55*2 | 60*2 | 65*2 | 70*2 |
| Screw L/D | 30|32:1 | 30|32:1 | 30|32:1 | 30|32:1 |
| Screw material | Double alloy material | Double alloy material | Double alloy material | Double alloy material |
| Barrel material | Double alloy material | Double alloy material | Double alloy material | Double alloy material |
| Barrel cooling fan | 550w*6 | 550w*6 | 550w*7 | 550w*8 |
| Main motor | 18.5kw*2 | 22kw*2 | 30kw*2 | 37kw*2 |
| Barrel temperature control | 3区*2 | 3区*2 | 3区*2 | 4区*2 |
| Average power consume | 40kw | 45kw | 60kw | 85kw |
| Die unit | ||||
| Die head | 80-100mm | 100-120mm | 120-180mm | 150-200mm |
| LDPE | 100-250mm | 220-320mm | 320-400mm | |
| Temperature control |
ZONE 10 |
ZONE 10 |
ZONE 12 |
|
| Air ring | Double vent air ring | Double vent air ring | Double vent air ring | Double vent air ring |
| Air blower | 5.5kw | 7.5kw | 7.5-11kw | 11kw |
| Roller width | 1100mm | 1300mm | 1600mm | 2000mm |
| Effictive width | 1000mm | 1200mm | 1500mm | 2050mm |
| Take-up speed | 10-120m/min | 10-120m/min | 10-120m/min | 10-120m/min |
| Take-up motor | 1.5kw | 1.5kw | 2.2kw | 3.7kw |
| Winding unit | Surface friction type | Surface friction type | Surface friction type | Surface friction type |
| Machine Weight | 4T | 4.5T | 5.5T | 7.5T |
| Voltage | 380V.50HZ.3PHASE | 380V.50HZ.3PHASE | 380V.50HZ.3PHASE | 380V.50HZ.3PHASE |
| Machine size (L*W*H) | 6*4*6.2m | 6*4*6.5m | 6*4*7.5m | 7*4.5*9.5m |
