Three Layers Co-extrusion Semi -Automatic Rotary Die Head Film Blowing Machine
|
Model |
CX-ABC-1300 |
CX-ABC-1600 |
CX-ABC-2200 |
|
Suitable materials |
HDPE,LDPE,LLDPE |
HDPE,LDPE,LLDPE |
HDPE,LDPE,LLDPE |
|
Film width |
600-1200mm |
1000-1500mm |
1500-2000mm |
|
Film thickness |
0.02-0.025mm |
0.02-0.025mm |
0.02-0.025mm |
|
Output |
180kg/h |
220kg/h |
280kg/h |
|
Extrusion unit |
|||
|
Screw diameter |
Φ50/Φ60/Φ55 |
Φ60/Φ65/Φ60 |
Φ65/Φ70/Φ65 |
|
Screw L/D |
30:1/32:1 |
30:1/32:1 |
30:1/32:1 |
|
Screw material |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
|
Barrel material |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
Sacm-645/38Crmoala |
|
Barrel cooling fan |
550w*6 |
550w*6 |
550w*9 |
|
Main motor |
18.5/22/18.5kw |
22/30/22kw |
30/37/30kw |
|
Barrel temperature control |
3*3 |
3*3 |
3*3 |
|
Average power consume |
60kw |
80kw |
100kw |
|
Die unit |
|||
|
Die head |
Φ250mm |
Φ320mm |
Φ400mm |
|
Temperature control |
13 |
15 |
15 |
|
Air ring |
Double air outlet wind ring |
Double air outlet wind ring |
Double air outlet wind ring |
|
Air blower |
7.5kw |
11kw |
11kw |
|
Take-up unit |
|||
|
Roller width |
1300mm |
1600mm |
2200mm |
|
Effictive width |
1200mm |
1500mm |
2000mm |
|
Take-up speed |
10-120m/min |
10-120m/min |
10-120m/min |
|
Take-up motor |
1.5kw |
2.2kw |
3.7kw |
|
Winding unit |
|||
|
Winding type |
Friction double winding |
Friction double winding |
Friction double winding |
|
Winding speed |
10-120m/min |
10-120m/min |
10-120m/min |
|
Voltage |
380V,50HZ,3PHASE |
380V,50HZ,3PHASE |
380V,50HZ,3PHASE |
|
Machine weight |
6T |
8T |
10T |
|
Machine size |
7.5*5.5*7.5m |
7.5*6*8.5m |
7.5*7*9.5m |
